Dr. Oppel’s electrode is not being heated by itself. Electrode lets the cellular tissue produce the joule heat, and operates hemostatis, cutting, and coagulation. 4MHz radio frequency makes possible precise cutting and deep coagulation even in blood.
There is no carbonization and damages to the surrounding cellular tissue by electric spark, and the safety secured. Specially developed various Bipolar and Monopolar electrodes for OB/GYN, PS/DER, Urology has outstanding performance in Micro Surgery by their excellent output time function.
The Distinctive Functions from other Electrosurgical Units and Lasers.
| System Type | Dr. Oppel ST 501 |
| Output Power | Monopolar : 130W ± 20% ( Average power on 100 Ω load) Bipolar : 90W ± 20% ( Average power on 50 Ω load) |
| Frequency | 4MHz |
| Input Voltage (customer-made) | 100 / 110 / 120 / 220 / 230 / 240 VAC, 50 / 60 Hz |
| Time Selection | Continous, 1sec, 1/2sec, 1/4sec, 1/8sec |
| Power Consumption | 400VA + 10% under on maximum load |
| Weight | 10 kg |
| Dimensions | Main unit : 225(W) X 300(L) X 166(H) mm |
